Regular Price
$240.40
Metal Wheel
8" x 1-3/4" Wide Wheel
2250 lb Load Capacity
Roller Bearing
Top Plate Mount
572°F Max Temp
Specifications
Dimensions & Mounting
| Wheel Diameter | 8" |
|---|---|
| Tread Width | 1-3/4" |
| Mount Height | 10-1/8" |
| Fastening Type | Top Plate |
| Fastening Size | 5-1/4" x 6-9/16" |
| Bolt Hole Spacing | 2-7/16" x 4-15/16" to 3-3/8" x 5-1/4" |
| Mounting Bolt Size | 1/2" |
| Swivel Radius | 10-1/8" |
Load & Performance
| Load Capacity | 2250 lbs |
|---|---|
| Bearing Type | Roller |
| Max Temperature | 572°F |
| Min Temperature | -58°F |
| Wheel Durometer | N/A (Metal) |
Materials & Finish
| Wheel Material | Metal |
|---|---|
| Wheel Color | Grey Metallic |
| Wheel Core | Cast Iron |
| Finish | Zinc Plated |
| Caster Type | Swivel |
| Brand / Series | Revvo H Series |
Delivery: Estimated delivery time: 2-3 days
Returns: 30 Days Returns
Volume discounts are available for bulk or frequent orders
Available Configurations
Product Details
About This Caster - TSH 200 CI15
Choose this 8-inch Revvo H Series cast iron swivel to steer the heaviest carts through extreme heat and the worst floors in the plant.
The big cast iron wheel carries through temperatures up to 572°F near furnaces and foundry work, and the tall 8-inch diameter clears wide cracks and debris that stop smaller wheels. The kingpinless swivel has no central bolt to shear under the shock of heavy material handling, and a roller bearing handles the weight at a slow pace. It steers with a 10-1/8-inch radius. The metal wheel is loud and marks floors, so it belongs on heavy industrial floors near heat. It serves from -58°F to 572°F.
Ideal applications
- Steering the heaviest carts near furnaces and kilns
- Broken floors and debris that destroy softer wheels
- Extreme-heat lead corners under maximum load
Confirm the roller-bearing load class on this 8-inch cast iron swivel and allow for the 10-1/8-inch swivel radius before ordering.
Pairs with: the matched 8-inch cast iron rigid TFH 200 CI15 at the rear.
Wrong fit? Need a cushioned ride? See the 8-inch rubber swivel TSH 200 RU15 in the Revvo collection.
Also in this family: the 10-inch cast iron swivel TSH 250 CI1H, or the full Revvo collection.
