6"x2" Cast Iron Swivel Caster - 110CA06201S

About This Caster - 110CA06201S

Reach for this 6-inch cast iron swivel on the steering corner of a hot, heavy cart that crosses debris, where a kingpin shears under the bump and a smaller wheel hangs up on scale.

The 6-inch diameter rolls over chips, spatter, and seams that stop a 4-inch wheel, and Albion's 110 Contender Kingpinless swivel rides a heat-treated raceway with no kingpin to shear or seize under side load. The grey cast iron wheel carries a hard, heavy load from -100 to 800°F, suited to foundry, oven, and heat-treat carts, and the roller bearing turns the load slowly. This is the plain swivel for corners that steer rather than park.

Ideal applications

• Steering corners crossing scale and debris on a hot cart
• Foundry, oven, and heat-treat rigs running to 800°F
• High-cycle routes where kingpin swivels shear under shock

For a corner that must hold the cart still, the face-brake 110CA06201SFBC locks the wheel.

Pairs with: the 110CA06201R rigid on the back corners so the front steers and the rear tracks.

Wrong fit? Finished floor, or a bigger wheel? See the polyurethane 110AX06228S and the 8-inch swivel 110CA08201S.

Also in this family: the 5-inch swivel 110CA05201S, or the full kingpinless caster collection.
