E-line Swivel 4"x2" Rubber USA-Made TPR Wheel 4"x4.5" Plate Caster; Part# ES4X2TPRB
Delivery: Estimated delivery time: 2-3 days
Returns: 30 Days Returns
Volume discounts are available for bulk or frequent orders
Available Configurations
Product Specifications
More Information About This Product
About This Caster - ES4X2TPRB
Set this 4-inch E-line swivel on the front corners of a towed cart that steers at speed, the wide-tread TPR caster whose precision ball bearing keeps the swivel rolling cool and true as the cart is pulled.
The swivel turns to steer the cart, and the precision ball bearing runs cool and true through a sustained pull where a plain bore would heat, which a towed front corner needs. The 4 by 4-1/2 top plate bolts to a flat deck, the 4-inch diameter keeps the deck low, and the wider 2-inch Pemco TPR rubber on a polypropylene core stays soft and quiet with no marks.
Ideal applications
- Front corners of towed carts that steer at speed
- Cool true swivel roll under a sustained pull
- Low bolt-on decks in the E-line load class
Skip the TPR wheel if the cart pushes the top of the E-line range or works near heat over 180°F; a TPU polyurethane or cast iron wheel handles it where soft rubber gives.
Pairs with: the ER4X2TPRB rigid on the back corners.
Wrong fit? Want a brake, or a wash bore? See the ES4X2TPRBTBK tread lock and the ES4X2TPRDTBK Delrin tread lock.
Also in this family: the 5-inch ES5X2TPRB, or the full Pemco collection.
