MFG PART: C0020120ZN-TPR01(GG)
2" Rubber Swivel Caster - C0020120ZN-TPR01(GG)
180 lbper caster
Regular Price
$10.34
Rubber Wheel
2" x 0.81" Wide Wheel
180 lb Load Capacity
Plain Bearing
Top Plate Mount
180°F Max Temp
Specifications
Dimensions & Mounting
| Wheel Diameter | 2" |
|---|---|
| Tread Width | 0.81" |
| Mount Height | 2-13/16" |
| Fastening Type | Top Plate |
| Fastening Size | 2-5/8" x 3-3/4" |
| Bolt Hole Spacing | 1-3/4" x 2-3/4" to 3" |
| Mounting Bolt Size | 5/16" |
| Swivel Radius | 2 |
Load & Performance
| Load Capacity | 180 lbs |
|---|---|
| Bearing Type | Plain |
| Max Temperature | 180°F |
| Min Temperature | -40°F |
| Wheel Durometer | 65(±5) Shore A |
Materials & Finish
| Wheel Material | Rubber |
|---|---|
| Wheel Color | Grey |
| Wheel Core | Polyolefin |
| Finish | Zinc Plated |
| Caster Type | Swivel |
| Brand / Series | Shepherd 00 Series |
Delivery: Estimated delivery time: 2-3 days
Returns: 30 Days Returns
Volume discounts are available for bulk or frequent orders
Available Configurations
Product Details
About This Caster - C0020120ZN-TPR01(GG)
Set this 2-inch top-plate swivel under equipment that has to move quietly and leave finished floors unmarked.
The wheel is soft grey thermoplastic rubber on a polyolefin core, a non-marking tread that rolls near-silent and cushions the small bumps and seams a hard wheel would clatter over, holding from -40 to 180°F. It bolts down through a 2-5/8 by 3-3/4 inch top plate, so it suits a flat equipment frame rather than a leg socket, and the low 2-13/16-inch height keeps the base close to the floor. This is the plain-swivel build, for corners that roll and steer.
Ideal applications
- Flat equipment frames that bolt to a 2-5/8 by 3-3/4 inch plate
- Offices, showrooms, and patient areas where quiet rolling matters
- Finished floors a hard wheel would mark or drum across
For a harder wheel that rolls lighter and takes 230°F, the polyolefin C0020741ZN-POL01(KK) swaps in on a threaded stem.
Pairs with: matching rubber top-plate swivels on the other corners of the same frame.
Wrong fit? Need a brake or a stem mount? See the side-brake C0020120ZN-TPR01(GG)B and the grip-ring C0020273ZN-POL01(KK).
Also in this family: the 1-1/2-inch-stem C0020748ZN-POL01(KK), or the full Shepherd collection.
