E-line Rigid 5"x2" Rubber USA-Made TPR Wheel 4"x4.5" Plate Caster; Part# ER5X2TPRB
Delivery: Estimated delivery time: 2-3 days
Returns: 30 Days Returns
Volume discounts are available for bulk or frequent orders
Available Configurations
Product Specifications
More Information About This Product
About This Caster - ER5X2TPRB
Set this 5-inch E-line rigid on the back corners of a tow cart that runs long and straight, the fixed TPR caster whose precision ball bearing keeps the taller rear rolling cool and true over distance.
A rigid caster tracks straight, and the precision ball bearing runs cool and true through a long sustained pull where a plain bore would heat, while the 5-inch diameter rolls the rear over a longer run and a thicker seam than a 4-inch. The 4 by 4-1/2 top plate bolts to a flat deck, and the wider 2-inch Pemco TPR rubber on a polypropylene core stays soft and quiet with no marks.
Ideal applications
- Back corners of long straight tow carts
- Cool true roll over distance on a taller rear
- Thicker seams a 5-inch rear bridges
Skip the TPR wheel if the cart loads near the top of its range or works near heat over 180°F; a TPU polyurethane or cast iron wheel runs it cooler where soft rubber gives.
Pairs with: a matching E-line swivel up front for a tow cart.
Wrong fit? Want a brake, or a heavy roller bore? See the ER5X2TPRBTBK tread lock and the ER5X2TPR roller.
Also in this family: the 6-inch ER6X2TPRB, or the full Pemco collection.
